Harris View Heel, The Magneto View A Simple Method For Obtaining Intraoperative Axial Radiographs Of The Calcaneus

5 an axial view of the calcaneus is obtained with the x ray source posterior to the heel and tilted caudally 450 with respect to the long axis of the foot.

Douglas emhoff ex wife kirsten. Sesamoid view. Bilateral calcaneal fractures are seen in 5 9. As applied to calcaneal.

She has pain throughout the day that worsens with prolonged weight bearing. Otherwise it may need surgery to realign the bone. If the fracture is not misaligned and no gap in the bone it can be treated with a cast.

Patient standing on x ray plate with knees in slight flexion central ray angles varies from 350 to 450 aimed posteriorly 5cm from prominence of posterior calcaneus for visualisation of middle and posterior subtalar joint facets. 29 and 210. 29 method of obtaining sesamoid view.

How do you fix a broken calcaneus. A shows the axis of the tibiab shows the surface of the distal tibia and c shows the surface of the proximal talusd shows the line from the top of the sustentaculum tali to the lateral inferior end of the posterior facet of the calcaneuse shows the horizontal line through the. Lateral heel view identifies posterior facet involvement bohlers angle critical angle of gissane and tuberosity position cranial migration.

On exam the location of maximal tenderness is indicated by the white arrow in figure a. Note the fracture line divides the calcaneus into anteromedial and posterolateral fragments. Axial view harris beath visualizes tuberosity position varus valgus primary fracture line calcaneal height loss calcaneal widening and a portion of the posterior facet.

As technology advances computed tomography ct has widely been used 1 to better visualize and characterize calcaneum fragment displacements and fracture lines. The ankle joint and the middle and posterior subtalar facets are visualised clearly. The harris view was first described in 1948 by harris and beath as a method of assessing for the presence of a talocalcaneal bridge in a rigid flat foot deformity.

A 48 year old member asked. Sbq12fa56 a 25 year old woman began training for a marathon and she reports a 2 week history of heel pain. The patient stands on the cassette and the x ray beam is angled between 35 and 45 degrees.

40 years experience podiatry. The calcaneus axial view is part of the two view calcaneus series assessing the talocalcaneal joint and plantar aspects of the calcaneus. Yet there remain many institutions especially in rural areas where ct is not readily available.

28 harris axial view of heel. This view is needed for diagnosing the problems of sesamoids figs. The talocalcaneal joint is exposed with the posterior facet laterally and the sustentacular facet medially.
